POS Segmented Barcodes

This screen allows you to create and maintain POS Segmented Barcode formats.

Segmented barcodes are normally used in retail environments which uses weighing scales like the Wedderburn.

Such scales normally produces segmented barcodes which contains the product code and weight or price of the purchase.

Entry and Display fields

Click Add button to add a record. Each record defines the format of the segmented barcode.

Start Position of Code: Enter the starting position of the product code (or product barcode) here.

End Position of Code: Enter the ending position of the product code (or product barcode) here.

Start Position of Qty: Enter the starting position of the quantity value. This could be a weight or price value.

End Position of Qty: Enter the ending position of the quantity value.

Barcode Length : Enter the total length of the segmented barcode.

Code Style: Options are : Product Barcode or  Product Code .

Product Barcode means the code portion of the segmented barcode is a product barcode.

Product Barcode is often used when the actual itemcode or descriptor code are too long to fit into the segmented barcode.

Product Code means the code portion of the segmented barcode is the itemcode or descriptorcode itself.

Buttons

Close: This will close the screen.  If you have any unsaved data then you will be asked if you wish to save it before the screen is closed.

Add: This will take you to a new line for creation of a new record.

Save: This will save the current data without exiting the screen

Cancel: Any changes made since the line was actioned or the last time the ‘Save’ Button was pressed will be lost.

Delete: This will delete the highlighted record.
