Hierarchical Structures
These screens allows you to create and maintain Hierarchical Structures which can be used to organise things like Items and Descriptors in a more structured format.
This is useful, for example, when organising a Sales Catalog of Items and Descriptors in the Freeway Mobility app where users can look for items in a more structured way.
List Tab
Display fields
Name: The name of the structure.
Description: Description of the hierarchical structure.
Notes: Additional notes relating to the purpose of this structure.
Data Display Options
Field Position - On the List screen you can move the field position by dragging the column heading left or right to the position where you want it to appear.
Filtering and Sorting - If you ‘check’ the checkbox then the displayed data is available for filtering and sorting:
|
• |
To sort the data in a selected column simply click on the column heading. Clicking against will sort in descending order. |
|
• |
Click on the black ‘down arrow’ to the right of your selected column heading and you can either select a specific entry to display all records containing that entry, or you can select (Custom ) to enter detailed selection criteria. |
Searching - If you enter some text into the ‘Search’ field and click on the ‘binoculars’ Icon then all records will be interrogated and those records that contain the entered text will be displayed. To revert back to displaying all records click on the ‘Eraser’ Icon
Buttons
Close: This will close the screen. If you have any unsaved data then you will be asked if you wish to save it before the screen is closed.
Add: This will take you to the ‘Details’ screen for entry of a new record.
Save: Not active in this view
Cancel: Not active in this view
Delete: This will delete the highlighted record
Detail Tab
Entry and Display fields
Name: Enter a name for the Hierarchical Structure. Duplicate names are not allowed. (Maximum 50 chars.)
Description: Add a brief description of the Structure. No checks are made on the entry but something must be entered. (Maximum 100 chars.)
Notes: Enter additional notes to explain the purpose of this structure.
Level1 to Level 4 Subtabs
Enter as many names as required to cover all possible items/descriptors at each level (up to 4 levels).
Level 1 is the top of the hierarchy, while Level 4 is the lowest.
Entry and Display fields
Seq No: Enter a sequence number.
Level Name: Enter a name of a group of items/descriptor that is at this Level.
Level Description: Enter a description for the Level Name
Image: Select a jpeg or png image which represents this group of items/descriptors.
Buttons
Close: This will close the screen. If you have any unsaved data then you will be asked if you wish to save it before the screen is closed.
Add: This will bring up a blank ‘Details’ screen for entry of a new record.
Save: This will save the current data without exiting the screen
Cancel: Any changes made to the record or the last time the ‘Save’ Button was pressed will be lost.
Delete: This will delete the current record
Hierarchy Tree Tab
This display-only tab will show the hierarchy you have defined in the Detail tab.
